In our previous tutorial, we discussed LeNet, a seminal Convolutional Neural Network in the deep learning and computer vision literature. VGGNet, (sometimes referred to as simply VGG), was first introduced by Simonyan and Zisserman in their 2014 paper, Very Deep Learning Convolutional Neural Networks for Large-Scale Image Recognition. The primary contribution of their work was demonstrating that an architecture with very small (3×3) filters can be trained to increasingly higher depths (16-19 layers) and obtain state-of-the-art classification on the challenging ImageNet classification challenge.
To learn how to implement a VGGNet, just keep reading.
MiniVGGNet: Going Deeper with CNNs
Previously, network architectures in the deep learning literature used a mix of filter sizes:
The first layer of the CNN usually includes filter sizes somewhere between 7×7 (Krizhevsky, Sutskever, and Hinton, 2012) and 11×11 (Sermanet et al., 2013). From there, filter sizes progressively reduced to 5×5. Finally, only the deepest layers of the network used 3×3 filters.
VGGNet is unique in that it uses 3×3 kernels throughout the entire architecture. The use of these small kernels is arguably what helps VGGNet generalize to classification problems outside where the network was originally trained.
Any time you see a network architecture that consists entirely of 3×3 filters, you can rest assured that it was inspired by VGGNet. Reviewing the entire 16 and 19 layer variants of VGGNet is too advanced for this introduction to Convolutional Neural Networks.
Instead, we are going to review the VGG family of networks and define what characteristics a CNN must exhibit to fit into this family. From there we’ll implement a smaller version of VGGNet called MiniVGGNet that can easily be trained on your system. This implementation will also demonstrate how to use two important layers — batch normalization (BN) and dropout.
The VGG Family of Networks
The VGG family of Convolutional Neural Networks can be characterized by two key components:
CONVlayers in the network using only 3×3 filters.
- Stacking multiple
CONV => RELUlayer sets (where the number of consecutive
CONV => RELUlayers normally increases the deeper we go) before applying a
In this tutorial, we are going to discuss a variant of the VGGNet architecture, which I call “MiniVGGNet” due to the fact that the network is substantially more shallow than its big brother.
Configuring your development environment
To follow this guide, you need to have the OpenCV library installed on your system.
Luckily, OpenCV is pip-installable:
$ pip install opencv-contrib-python
If you need help configuring your development environment for OpenCV, I highly recommend that you read my pip install OpenCV guide — it will have you up and running in a matter of minutes.
Having problems configuring your development environment?
All that said, are you:
- Short on time?
- Learning on your employer’s administratively locked system?
- Wanting to skip the hassle of fighting with the command line, package managers, and virtual environments?
- Ready to run the code right now on your Windows, macOS, or Linux system?
Then join PyImageSearch University today!
Gain access to Jupyter Notebooks for this tutorial and other PyImageSearch guides that are pre-configured to run on Google Colab’s ecosystem right in your web browser! No installation required.
And best of all, these Jupyter Notebooks will run on Windows, macOS, and Linux!
The (Mini) VGGNet Architecture
In both ShallowNet and LeNet we have applied a series of
CONV => RELU => POOL layers. However, in VGGNet, we stack multiple
CONV => RELU layers prior to applying a single
POOL layer. Doing this allows the network to learn more rich features from the
CONV layers prior to downsampling the spatial input size via the
Overall, MiniVGGNet consists of two sets of
CONV => RELU => CONV => RELU => POOL layers, followed by a set of
FC => RELU => FC => SOFTMAX layers. The first two
CONV layers will learn 32 filters, each of size 3×3. The second two
CONV layers will learn 64 filters, again, each of size 3×3. Our
POOL layers will perform max pooling over a 2×2 window with a 2×2 stride. We’ll also be inserting batch normalization layers after the activations along with dropout layers (
DO) after the
The network architecture itself is detailed in Table 1, where the initial input image size is assumed to be 32×32×3.
Again, notice how the batch normalization and dropout layers are included in the network architecture based on my “Rules of Thumb” in Convolutional Neural Networks (CNNs) and Layer Types. Applying batch normalization will help reduce the effects of overfitting and increase our classification accuracy on CIFAR-10.
Given the description of MiniVGGNet in Table 1, we can now implement the network architecture using Keras. To get started, add a new file named
minivggnet.py inside the
pyimagesearch.nn.conv sub-module — this is where we will write our MiniVGGNet implementation:
--- pyimagesearch | |--- __init__.py | |--- nn | | |--- __init__.py ... | | |--- conv | | | |--- __init__.py | | | |--- lenet.py | | | |--- minivggnet.py | | | |--- shallownet.py
After creating the
minivggnet.py file, open it in your favorite code editor and we’ll get to work:
# import the necessary packages from tensorflow.keras.models import Sequential from tensorflow.keras.layers import BatchNormalization from tensorflow.keras.layers import Conv2D from tensorflow.keras.layers import MaxPooling2D from tensorflow.keras.layers import Activation from tensorflow.keras.layers import Flatten from tensorflow.keras.layers import Dropout from tensorflow.keras.layers import Dense from tensorflow.keras import backend as K
Lines 2-10 import our required classes from the Keras library. Most of these imports you have already seen before, but I want to bring your attention to the
BatchNormalization (Line 3) and
Dropout (Line 8) — these classes will enable us to apply batch normalization and dropout to our network architecture.
Just like our implementations of both ShallowNet and LeNet, we’ll define a
build method that can be called to construct the architecture using a supplied
depth, and number of
class MiniVGGNet: @staticmethod def build(width, height, depth, classes): # initialize the model along with the input shape to be # "channels last" and the channels dimension itself model = Sequential() inputShape = (height, width, depth) chanDim = -1 # if we are using "channels first", update the input shape # and channels dimension if K.image_data_format() == "channels_first": inputShape = (depth, height, width) chanDim = 1
Line 17 instantiates the
Sequential class, the building block of sequential neural networks in Keras. We then initialize the
inputShape, assuming we are using channels last ordering (Line 18).
Line 19 introduces a variable we haven’t seen before,
chanDim, the index of the channel dimension. Batch normalization operates over the channels, so in order to apply BN, we need to know which axis to normalize over. Setting
chanDim = -1 implies that the index of the channel dimension last in the input shape (i.e., channels last ordering). However, if we are using channels first ordering (Lines 23-25), we need to update the
inputShape and set
chanDim = 1, since the channel dimension is now the first entry in the input shape.
The first layer block of MiniVGGNet is defined below:
# first CONV => RELU => CONV => RELU => POOL layer set model.add(Conv2D(32, (3, 3), padding="same", input_shape=inputShape)) model.add(Activation("relu")) model.add(BatchNormalization(axis=chanDim)) model.add(Conv2D(32, (3, 3), padding="same")) model.add(Activation("relu")) model.add(BatchNormalization(axis=chanDim)) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Dropout(0.25))
Here, we can see our architecture consists of
(CONV => RELU => BN) * 2 => POOL => DO. Line 28 defines a
CONV layer with 32 filters, each of which has a 3×3 filter size. We then apply a ReLU activation (Line 30) which is immediately fed into a
BatchNormalization layer (Line 31) to zero-center the activations.
However, instead of applying a
POOL layer to reduce the spatial dimensions of our input, we instead apply another set of
CONV => RELU => BN — this allows our network to learn more rich features, a common practice when training deeper CNNs.
On Line 35, we use
MaxPooling2D with a size of 2×2. Since we do not explicitly set a stride, Keras implicitly assumes our stride to be equal to the max pooling size (which is 2×2).
We then apply
Dropout on Line 36 with a probability of p = 0.25, implying that a node from the
POOL layer will be randomly disconnected from the next layer with a probability of 25% during training. We apply dropout to help reduce the effects of overfitting. You can read more about dropout in a separate lesson. We then add the second layer block to MiniVGGNet below:
# second CONV => RELU => CONV => RELU => POOL layer set model.add(Conv2D(64, (3, 3), padding="same")) model.add(Activation("relu")) model.add(BatchNormalization(axis=chanDim)) model.add(Conv2D(64, (3, 3), padding="same")) model.add(Activation("relu")) model.add(BatchNormalization(axis=chanDim)) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Dropout(0.25))
The code above follows the exact same pattern as the above; however, now we are learning two sets of 64 filters (each of size 3×3) as opposed to 32 filters. Again, it is common to increase the number of filters as the spatial input size decreases deeper in the network.
Next comes our first (and only) set of
FC => RELU layers:
# first (and only) set of FC => RELU layers model.add(Flatten()) model.add(Dense(512)) model.add(Activation("relu")) model.add(BatchNormalization()) model.add(Dropout(0.5))
FC layer has
512 nodes, which will be followed by a ReLU activation and BN. We’ll also apply dropout here, increasing the probability to 50% — typically you’ll see dropout with p = 0.5 applied in between
Finally, we apply the softmax classifier and return the network architecture to the calling function:
# softmax classifier model.add(Dense(classes)) model.add(Activation("softmax")) # return the constructed network architecture return model
Now that we’ve implemented the MiniVGGNet architecture, let’s move on to applying it to CIFAR-10.
MiniVGGNet on CIFAR-10
We will follow a similar pattern training MiniVGGNet as we did for LeNet in the previous tutorial, only this time with the CIFAR-10 dataset:
- Load the CIFAR-10 dataset from disk.
- Instantiate the MiniVGGNet architecture.
- Train MiniVGGNet using the training data.
- Evaluate network performance with the testing data.
To create a driver script to train MiniVGGNet, open a new file, name it
minivggnet_cifar10.py, and insert the following code:
# set the matplotlib backend so figures can be saved in the background import matplotlib matplotlib.use("Agg") # import the necessary packages from sklearn.preprocessing import LabelBinarizer from sklearn.metrics import classification_report from pyimagesearch.nn.conv import MiniVGGNet from tensorflow.keras.optimizers import SGD from tensorflow.keras.datasets import cifar10 import matplotlib.pyplot as plt import numpy as np import argparse
Line 2 imports the
matplotlib library which we’ll later use to plot our accuracy and loss over time. We need to set the
matplotlib backend to
Agg to indicate to create a non-interactive that will simply be saved to disk. Depending on what your default
matplotlib backend is and whether you are accessing your deep learning machine remotely (via SSH, for instance), X11 session may timeout. If that happens,
matplotlib will error out when it tries to display your figure. Instead, we can simply set the background to
Agg and write the plot to disk when we are done training our network.
Lines 9-13 import the rest of our required Python packages, all of which you’ve seen before — the exception being
MiniVGGNet on Line 8, which we implemented earlier.
Next, let’s parse our command line arguments:
# construct the argument parse and parse the arguments ap = argparse.ArgumentParser() ap.add_argument("-o", "--output", required=True, help="path to the output loss/accuracy plot") args = vars(ap.parse_args())
This script will require only a single command line argument,
--output, the path to our output training and loss plot.
We can now load the CIFAR-10 dataset (pre-split into training and testing data), scale the pixels into the range
[0, 1], and then one-hot encode the labels:
# load the training and testing data, then scale it into the # range [0, 1] print("[INFO] loading CIFAR-10 data...") ((trainX, trainY), (testX, testY)) = cifar10.load_data() trainX = trainX.astype("float") / 255.0 testX = testX.astype("float") / 255.0 # convert the labels from integers to vectors lb = LabelBinarizer() trainY = lb.fit_transform(trainY) testY = lb.transform(testY) # initialize the label names for the CIFAR-10 dataset labelNames = ["airplane", "automobile", "bird", "cat", "deer", "dog", "frog", "horse", "ship", "truck"]
Let’s compile our model and start training MiniVGGNet:
# initialize the optimizer and model print("[INFO] compiling model...") opt = SGD(lr=0.01, decay=0.01 / 40, momentum=0.9, nesterov=True) model = MiniVGGNet.build(width=32, height=32, depth=3, classes=10) model.compile(loss="categorical_crossentropy", optimizer=opt, metrics=["accuracy"]) # train the network print("[INFO] training network...") H = model.fit(trainX, trainY, validation_data=(testX, testY), batch_size=64, epochs=40, verbose=1)
We’ll use SGD as our optimizer with a learning rate of α = 0.01 and momentum term of γ = 0.9. Setting
nestrov=True indicates that we would like to apply Nestrov accelerated gradient to the SGD optimizer.
An optimizer term we haven’t seen yet is the
decay parameter. This argument is used to slowly reduce the learning rate over time. Decaying the learning rate is helpful in reducing overfitting and obtaining higher classification accuracy — the smaller the learning rate is, the smaller the weight updates will be. A common setting for
decay is to divide the initial learning rate by the total number of epochs — in this case, we’ll be training our network for a total of 40 epochs with an initial learning rate of 0.01, therefore
decay = 0.01 / 40.
After training completes, we can evaluate the network and display a nicely formatted classification report:
# evaluate the network print("[INFO] evaluating network...") predictions = model.predict(testX, batch_size=64) print(classification_report(testY.argmax(axis=1), predictions.argmax(axis=1), target_names=labelNames))
And with save our loss and accuracy plot to disk:
# plot the training loss and accuracy plt.style.use("ggplot") plt.figure() plt.plot(np.arange(0, 40), H.history["loss"], label="train_loss") plt.plot(np.arange(0, 40), H.history["val_loss"], label="val_loss") plt.plot(np.arange(0, 40), H.history["accuracy"], label="train_acc") plt.plot(np.arange(0, 40), H.history["val_accuracy"], label="val_acc") plt.title("Training Loss and Accuracy on CIFAR-10") plt.xlabel("Epoch #") plt.ylabel("Loss/Accuracy") plt.legend() plt.savefig(args["output"])
When evaluating MinIVGGNet, I performed two experiments:
- One with batch normalization.
- One without batch normalization.
Let’s go ahead and take a look at these results to compare how network performance increases when applying batch normalization.
With Batch Normalization
To train MiniVGGNet on the CIFAR-10 dataset, just execute the following command:
$ python minivggnet_cifar10.py --output output/cifar10_minivggnet_with_bn.png [INFO] loading CIFAR-10 data... [INFO] compiling model... [INFO] training network... Train on 50000 samples, validate on 10000 samples Epoch 1/40 23s - loss: 1.6001 - acc: 0.4691 - val_loss: 1.3851 - val_acc: 0.5234 Epoch 2/40 23s - loss: 1.1237 - acc: 0.6079 - val_loss: 1.1925 - val_acc: 0.6139 Epoch 3/40 23s - loss: 0.9680 - acc: 0.6610 - val_loss: 0.8761 - val_acc: 0.6909 ... Epoch 40/40 23s - loss: 0.2557 - acc: 0.9087 - val_loss: 0.5634 - val_acc: 0.8236 [INFO] evaluating network... precision recall f1-score support airplane 0.88 0.81 0.85 1000 automobile 0.93 0.89 0.91 1000 bird 0.83 0.68 0.75 1000 cat 0.69 0.65 0.67 1000 deer 0.74 0.85 0.79 1000 dog 0.72 0.77 0.74 1000 frog 0.85 0.89 0.87 1000 horse 0.85 0.87 0.86 1000 ship 0.89 0.91 0.90 1000 truck 0.88 0.91 0.90 1000 avg / total 0.83 0.82 0.82 10000
On my GPU, epochs were quite fast at 23s. On my CPU, epochs were considerably longer, clocking in at 171s.
After training completed, we can see that MiniVGGNet is obtaining 83% classification accuracy on the CIFAR-10 dataset with batch normalization — this result is substantially higher than the 60% accuracy when applying ShallowNet in a separate tutorial. We thus see how a deeper network architectures are able to learn richer, more discriminative features.
Without Batch Normalization
Go back to the
minivggnet.py implementation and comment out all
BatchNormalization layers, like so:
# first CONV => RELU => CONV => RELU => POOL layer set model.add(Conv2D(32, (3, 3), padding="same", input_shape=inputShape)) model.add(Activation("relu")) #model.add(BatchNormalization(axis=chanDim)) model.add(Conv2D(32, (3, 3), padding="same")) model.add(Activation("relu")) #model.add(BatchNormalization(axis=chanDim)) model.add(MaxPooling2D(pool_size=(2, 2))) model.add(Dropout(0.25))
Once you’ve commented out all
BatchNormalization layers from your network, re-train MiniVGGNet on CIFAR-10:
$ python minivggnet_cifar10.py \ --output output/cifar10_minivggnet_without_bn.png [INFO] loading CIFAR-10 data... [INFO] compiling model... [INFO] training network... Train on 50000 samples, validate on 10000 samples Epoch 1/40 13s - loss: 1.8055 - acc: 0.3426 - val_loss: 1.4872 - val_acc: 0.4573 Epoch 2/40 13s - loss: 1.4133 - acc: 0.4872 - val_loss: 1.3246 - val_acc: 0.5224 Epoch 3/40 13s - loss: 1.2162 - acc: 0.5628 - val_loss: 1.0807 - val_acc: 0.6139 ... Epoch 40/40 13s - loss: 0.2780 - acc: 0.8996 - val_loss: 0.6466 - val_acc: 0.7955 [INFO] evaluating network... precision recall f1-score support airplane 0.83 0.80 0.82 1000 automobile 0.90 0.89 0.90 1000 bird 0.75 0.69 0.71 1000 cat 0.64 0.57 0.61 1000 deer 0.75 0.81 0.78 1000 dog 0.69 0.72 0.70 1000 frog 0.81 0.88 0.85 1000 horse 0.85 0.83 0.84 1000 ship 0.90 0.88 0.89 1000 truck 0.84 0.89 0.86 1000 avg / total 0.79 0.80 0.79 10000
The first thing you’ll notice is that your network trains faster without batch normalization (13s compared to 23s, a reduction by 43%). However, once the network finishes training, you’ll notice a lower classification accuracy of 79%.
When we plot MiniVGGNet with batch normalization (left) and without batch normalization (right) side-by-side in Figure 2, we can see the positive effect batch normalization has on the training process:
Notice how the loss for MiniVGGNet without batch normalization starts to increase past epoch 30, indicating that the network is overfitting to the training data. We can also clearly see that validation accuracy has become quite saturated by epoch 25.
On the other hand, the MiniVGGNet implementation with batch normalization is more stable. While both loss and accuracy start to flatline past epoch 35, we aren’t overfitting as badly — this is one of the many reasons why I suggest applying batch normalization to your own network architectures.
