In our previous tutorial, you learned how to train your first Convolutional Neural Network using the Keras library. However, you might have noticed that each time you wanted to evaluate your network or test it on a set of images, you first needed to train it before you could do any type of evaluation. This requirement can be quite the nuisance.
We are only working with a shallow network on a small dataset that can be trained relatively quickly, but what if our network was deep and we needed to train it on a much larger dataset, thus taking many hours or even days to train? Would we have to invest this amount of time and resources to train our network each and every time? Or is there a way to save our model to disk after training is complete and then simply load it from disk when we want to classify new images?
You bet there’s a way. The process of saving and loading a trained model is called model serialization and is the primary topic of this tutorial.
To learn how to serialize a model, just keep reading.
Configuring your development environment
To follow this guide, you need to have the OpenCV library installed on your system.
Luckily, OpenCV is pip-installable:
$ pip install opencv-contrib-python
If you need help configuring your development environment for OpenCV, I highly recommend that you read my pip install OpenCV guide — it will have you up and running in a matter of minutes.
Having problems configuring your development environment?
All that said, are you:
- Short on time?
- Learning on your employer’s administratively locked system?
- Wanting to skip the hassle of fighting with the command line, package managers, and virtual environments?
- Ready to run the code right now on your Windows, macOS, or Linux system?
Then join PyImageSearch University today!
Gain access to Jupyter Notebooks for this tutorial and other PyImageSearch guides that are pre-configured to run on Google Colab’s ecosystem right in your web browser! No installation required.
And best of all, these Jupyter Notebooks will run on Windows, macOS, and Linux!
Serializing a Model to Disk
Using the Keras library, model serialization is as simple as calling
model.save on a trained model and then loading it via the
load_model function. In the first part of this tutorial, we’ll modify a ShallowNet training script from the previous tutorial to serialize the network after it’s been trained on the Animals dataset. We’ll then create a second Python script that demonstrates how to load our serialized model from disk.
Let’s get started with the training part — open up a new file, name it
shallownet_train.py, and insert the following code:
# import the necessary packages from sklearn.preprocessing import LabelBinarizer from sklearn.model_selection import train_test_split from sklearn.metrics import classification_report from pyimagesearch.preprocessing import ImageToArrayPreprocessor from pyimagesearch.preprocessing import SimplePreprocessor from pyimagesearch.datasets import SimpleDatasetLoader from pyimagesearch.nn.conv import ShallowNet from tensorflow.keras.optimizers import SGD from imutils import paths import matplotlib.pyplot as plt import numpy as np import argparse
Lines 2-13 import our required Python packages. Much of the code in this example is identical to
shallownet_animals.py from “A gentle guide to training your first CNN with Keras and TensorFlow.” We’ll review the entire file, for the sake of completeness, and I’ll be sure to call out the important changes made to accomplish model serialization, but for a detailed review of how to train ShallowNet on the Animals dataset, please refer to the previous tutorial.
Next, let’s parse our command line arguments:
# construct the argument parse and parse the arguments ap = argparse.ArgumentParser() ap.add_argument("-d", "--dataset", required=True, help="path to input dataset") ap.add_argument("-m", "--model", required=True, help="path to output model") args = vars(ap.parse_args())
Our previous script only required a single switch,
--dataset, which is the path to the input Animals dataset. However, as you can see, we’ve added another switch here —
--model, which is the path to where we would like to save the network after training is complete.
We can now grab the paths to the images in our
--dataset, initialize our preprocessors, and load our image dataset from disk:
# grab the list of images that we'll be describing print("[INFO] loading images...") imagePaths = list(paths.list_images(args["dataset"])) # initialize the image preprocessors sp = SimplePreprocessor(32, 32) iap = ImageToArrayPreprocessor() # load the dataset from disk then scale the raw pixel intensities # to the range [0, 1] sdl = SimpleDatasetLoader(preprocessors=[sp, iap]) (data, labels) = sdl.load(imagePaths, verbose=500) data = data.astype("float") / 255.0
The next step is to partition our data into training and testing splits, along with encoding our labels as vectors:
# partition the data into training and testing splits using 75% of # the data for training and the remaining 25% for testing (trainX, testX, trainY, testY) = train_test_split(data, labels, test_size=0.25, random_state=42) # convert the labels from integers to vectors trainY = LabelBinarizer().fit_transform(trainY) testY = LabelBinarizer().fit_transform(testY)
Training ShallowNet is handled via the code block below:
# initialize the optimizer and model print("[INFO] compiling model...") opt = SGD(lr=0.005) model = ShallowNet.build(width=32, height=32, depth=3, classes=3) model.compile(loss="categorical_crossentropy", optimizer=opt, metrics=["accuracy"]) # train the network print("[INFO] training network...") H = model.fit(trainX, trainY, validation_data=(testX, testY), batch_size=32, epochs=100, verbose=1)
Now that our network is trained, we need to save it to disk. This process is as simple as calling
model.save and supplying the path to where our output network should be saved to disk:
# save the network to disk print("[INFO] serializing network...") model.save(args["model"])
.save method takes the weights and state of the optimizer and serializes them to disk in HDF5 format. Loading these weights from disk is just as easy as saving them.
From here we evaluate our network:
# evaluate the network print("[INFO] evaluating network...") predictions = model.predict(testX, batch_size=32) print(classification_report(testY.argmax(axis=1), predictions.argmax(axis=1), target_names=["cat", "dog", "panda"]))
As well as plot our loss and accuracy:
# plot the training loss and accuracy plt.style.use("ggplot") plt.figure() plt.plot(np.arange(0, 100), H.history["loss"], label="train_loss") plt.plot(np.arange(0, 100), H.history["val_loss"], label="val_loss") plt.plot(np.arange(0, 100), H.history["accuracy"], label="train_acc") plt.plot(np.arange(0, 100), H.history["val_accuracy"], label="val_acc") plt.title("Training Loss and Accuracy") plt.xlabel("Epoch #") plt.ylabel("Loss/Accuracy") plt.legend() plt.show()
To run our script, simply execute the following command:
$ python shallownet_train.py --dataset ../datasets/animals \ --model shallownet_weights.hdf5
After the network has finished training, list the contents of your directory:
$ ls shallownet_load.py shallownet_train.py shallownet_weights.hdf5
And you will see a file named
shallownet_weights.hdf5 — this file is our serialized network. The next step is to take this saved network and load it from disk.
Congratulations, now you know how to save your Keras and TensorFlow model to disk. As you saw, it’s as simple as calling
model.save and supplying the path to where our output network should be saved. Now you know how to train a model and save it so you don’t need to start from scratch each and every time you train a model.
